Passband frequency: 22.7 ~ 22.9 GHz

Passband insertion loss: ≤0.35 dB

Out-of-band rejection: ≥40 dB @ 18 ~ 21.2 GHz;
≥30 dB @ 45.4 ~ 45.8 GHz and 68.1 ~ 68.7 GHz

VSWR: ≤1.2

Power handling (CW): ≥400 W

Flange interface: FBM/FBP220

Material and coating: Copper with silver plating, exterior surface painted
