Operating Voltage: +9V~+16V DC
Current: <230mA @12V
Operating Frequency Range: 76GHz~77GHz
Maximum Transmit Power: ≤55dBm peak EIRP
Data Update Time: 50ms
Distance Range: 0.5~100m (RCS = 10dBsm)
Distance Accuracy: <±2.5% or ±0.3m
Distance Resolution: 0.6m
Relative Speed Range: -60m/s~+60m/s
Relative Speed Accuracy: ±0.23m/s
Speed Resolution: 0.42m/s
Angular Range (Horizontal): 150° (RCS = 10dBsm)
Angular Accuracy: ±1° (within ±15°)
Angular Resolution: 8°
Angular Range (Vertical): 15°
Protection Rating: IP6K7
