Operating voltage: 12V
Operating current: <300mA @12V
Operating frequency: 78GHz~80GHz
Transmit power: 20dBm
Data update time: 50ms
Measurement range: 0.1~6m
Accuracy: ±0.05m
Application scenarios: UAV obstacle avoidance, AGV obstacle avoidance, construction vehicle obstacle avoidance
Horizontal angle range: 120°
Pitch angle range: 120°
Data interface: 485
Operating temperature range: -40°C ~ 85°C
Dimensions: 110mm * 80mm
